library(tidyverse)
library(tidymodels)
library(tidyquant)

#30-year Treasury yield (^TYX)
df_yield_30 <-
  tq_get("^TYX") %>%
  tq_transmute(select = close,
               mutate_fun = to.monthly,
               col_rename = "yield_30") %>%
  mutate(date = as.Date(date))

#Federal Surplus or Deficit [-] (MTSDS133FMS)
df_deficit <-
  tq_get("MTSDS133FMS", get = "economic.data") %>%
  select(date, deficit = price)

#Merging the datasets
df_merged <-
  df_yield_30 %>%
  left_join(df_deficit) %>%
  drop_na()

#Data split
splits <- initial_time_split(df_merged, prop = 0.8)
df_train <- training(splits)
df_test <- testing(splits)

#Bootstrapping for tuning
set.seed(12345)
df_folds <- bootstraps(df_train,
                       times = 100)
#Model
model_spec <-
  boost_tree(trees = tune(),
             learn_rate = tune()) %>%
  set_engine("xgboost") %>%
  set_mode("regression")

#Preprocessing
recipe_spec <-
  recipe(yield_30 ~ ., data = df_train) %>%
  step_date(date, features = "month", ordinal = FALSE) %>%
  step_dummy(all_nominal_predictors(), one_hot = TRUE) %>%
  step_mutate(date_num = as.numeric(date)) %>%
  step_normalize(all_numeric_predictors()) %>%
  step_rm(date)


#Workflow sets
wflow_xgboost <-
  workflow_set(
    preproc = list(recipe = recipe_spec),
    models = list(model = model_spec)
  )


#Tuning and evaluating all the models
grid_ctrl <-
  control_grid(
    save_pred = TRUE,
    parallel_over = "everything",
    save_workflow = TRUE
  )

grid_results <-
  wflow_xgboost %>%
  workflow_map(
    seed = 98765,
    resamples = df_folds,
    grid = 10,
    control = grid_ctrl
  )

#Accuracy of the grid results
grid_results %>%
  rank_results(select_best = TRUE,
               rank_metric = "rsq") %>%
  select(Models = wflow_id, .metric, mean)


#Finalizing the model with the best parameters
best_param <-
  grid_results %>%
  extract_workflow_set_result("recipe_model") %>%
  select_best(metric = "rsq")


wflw_fit <-
  grid_results %>%
  extract_workflow("recipe_model") %>%
  finalize_workflow(best_param) %>%
  fit(df_train)


#Variable importance
library(DALEXtra)

#Processed data frame for variable importance calculation
imp_data <-
  recipe_spec %>%
  prep() %>%
  bake(new_data = NULL)

#Explainer object
explainer_xgboost <-
  explain_tidymodels(
    wflw_fit %>% extract_fit_parsnip(),
    data = imp_data %>% select(-yield_30),
    y = imp_data$yield_30,
    label = "",
    verbose = FALSE
  )


#Calculating permutation-based variable importance
set.seed(1983)
vip_xgboost <- model_parts(explainer_xgboost,
                           loss_function = loss_root_mean_square,
                           type = "difference",
                           B = 100,#the number of permutations
                           label = "")

#Plot VIP
vip_xgboost %>%
  plot() +
  labs(color = "",
       x = "",
       y = "",
       subtitle = "Higher indicates more important",
       title = "Factors Affecting 30-year Treasury Yield") +
  theme_minimal(base_family = "Roboto Slab",
                base_size = 16) +
  theme(legend.position = "none",
        plot.title = element_text(hjust = 0.5,
                                  size = 14,
                                  face = "bold"),
        plot.subtitle = element_text(hjust = 0.5, size = 12),
        panel.grid.minor.x = element_blank(),
        panel.grid.major.y = element_blank(),
        plot.background = element_rect(fill = "azure"))
